Long-range FPV Project Ideas for Hobbyists: ELRS, GPS Rescue and Robust Failsafes.
Long-range FPV opens up thrilling possibilities for hobbyists who enjoy exploration and optimisation, and the projects below are geared towards safe, practical builds that extend range without compromising reliability or legality. Before you start any long-range project, check local aviation regulations and prioritise line-of-sight where required, and plan flights with safety as the primary objective.
ExpressLRS (ELRS) is the most popular low-latency, open-source radio link for long-range hobbyists, and a project to create a light-weight ELRS ground station and portable antenna mast is highly rewarding. Focus on setting sensible RF power and CRSF packet rates in the transmitter module and receiver, log RSSI and packet loss during test flights, and experiment with module heatsinking and tuning to keep performance stable. Building a compact crab-style ground box with an external battery, a protractor-style tilt mount and a small diversity switch is a practical weekend project that teaches RF basics and improves real-world reliability.
GPS rescue systems add a valuable layer of redundancy and are worth integrating as a dedicated project, especially on long-range rigs that may cross unfamiliar terrain. Configure your flight controller to invoke GPS rescue at a defined RSSI or when the ELRS failsafe triggers, set a sensible safe altitude and verify behaviour in controlled tests. Remember to calibrate compasses and separate the GNSS antenna from high-current wiring and ESCs to avoid magnetic and RF interference, and document each test so that rescue behaviour becomes repeatable and trustworthy.
Efficient propulsion is central to endurance projects, so select motors and propellers with an eye to efficiency rather than pure thrust, and match motor KV to your chosen battery voltage for lower cruise throttle. A practical experiment is swapping three propeller sizes and logging current draw, climb rates and throttle percentage needed for cruise to identify the best combination for distance. Use high-quality ESCs with BLHeli_32 or similar firmware for smooth current control, keep props balanced, and consider high-capacity LiPo or energy-dense Li-ion packs for flights where charging options are limited.
Correct antenna placement is an often-overlooked project that pays dividends in range and consistency, so build mounts that lift antennas away from carbon fibre and noisy electronics. On the airframe, position receiver antennas orthogonally for polarisation diversity and keep them above or below the FC to reduce interference, and on the ground use a high-gain directional antenna or a steerable patch for long-distance legs. A simple project is to fabricate a lightweight, removable antenna boom for the quad or plane and test different polarisation angles and mast heights to map reception under varying terrain.
Failsafe and redundancy projects turn a good long-range build into a reliable one, so start by programming ELRS failsafe behaviours to set throttle to a safe idle or to trigger a return rather than a motor cut. Combine ELRS radio failsafe with flight controller failsafe actions, log all failsafe events to an on-board SD card or OSD, and consider mechanical redundancies such as a small drogue or parachute for heavier models. If you want full build logs and parts lists for several long-range setups, see my site at WatDaFeck for step-by-step guides and photos.
Project ideas to try at home include assembling a portable ELRS ground station with antenna rotator, installing and tuning GPS rescue on a light-weight long-range airplane, experimenting with low KV motors and oversized props for efficient cruising, testing antenna placement with a signal-mapping walk, and designing a failsafe checklist and logger that records link and GPS health during each flight.
