Build Log: Multi-Speed RC Truck and Hauler with Scale Gearboxes and Trailer Detail
This build log documents a step-by-step hobbyist project to create a realistic RC truck and heavy hauler, concentrating on robust gearboxes, a multi-speed drive system, and an accurately detailed trailer. The aim was a truck that can crawl low-speed with heavy loads and also cruise realistically on-road, while looking like a 1/14 or 1/16 scale commercial rig when parked. The process below covers planning, parts, assembly, testing and finishing touches for a single complete build.
Step one was planning the chassis layout and selecting the drivetrain components that would support a multi-speed arrangement and trailer loads. I started with a long-wheelbase ladder chassis made from 3D-printed reinforcement plates and aluminium rails to keep weight low and rigidity high. For the gearbox I compared small planetary units for compact reduction with a more traditional spur-bevel layout that allows easier multi-speed integration. I specified metal gears for durability, sealed bearings for alignment, and a servo-actuated shift mechanism to change ratios under no-load conditions.
The gearbox assembly was a key step and required careful measurement and test-fitting before finalising the housings. I designed a two-speed transmission using interchangeable gearsets: a low-range spur set for torque and a high-range set for speed, both sharing the same input shaft with a sliding dog-clutch actuated by a micro-servo. The transfer case uses bevel gears to route power to the rear axles and a simple locking differential was added for scale behaviour on uneven surfaces. During assembly I fitted shims to eliminate endplay, used thread-lock on fasteners that experience torque, and tested the system on a bench with incremental load cycles to watch temperature and gear mesh under load.
The trailer and coupling required as much thought as the truck because a realistic hauler needs good articulation and correct load distribution. I built a heavy-duty fifth wheel plate from brass and 3D-printed the kingpin housing to allow smooth pivot and a little lateral play for cornering realism. The trailer chassis uses tandem bogies with scale air-suspension bellows printed in flexible filament for appearance, while hidden spring pickups provide functional weight transfer on rough terrain. Lighting and electrics run through a quick-connect between truck and trailer so I could test brake and marker lights independently, and I added a small dolly assembly for low-speed backing practice that mimics the behaviour of real artic combinations.
Scale detail finished the model and brought the project to life, from tiny mudflaps and toolbox faces to accurately routed pneumatic lines and battery boxes that look like diesel tanks. I added a cab interior with print-in-place seats and a dashboard, and weathered the paint with washes and dry-brushing to sell the scale. For control I tuned the ESC to allow very low throttle for precise trailer manoeuvres and programmed a second channel to control the gearbox servo so shifting is crisp and repeatable. I kept a parts list and printable brackets on my site WatDaFeck for anyone following the build and to make it easier to source the components I used.
